Monobloc Burner Range
Light Oil burners
One Stage
40
The Riello 40 F series of one stage light oil burners, is a complete range of products developed to respond to any request for light industrial applications. The Riello 40 F series is available in three different models, with an
output ranging from 30 to 202 kW, divided in three different structures.
All the models use the same components designed by Riello for the Riello 40 F series. The high quality level guarantees safe working.
In developing these burners, special attention was paid to reducing noise, to the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
All the models are approved by the EN 267 European Standard and conform to European Directives for EMC, Low Voltage, Machinery and Boiler Efficiency.
RG 2
The Riello Gulliver RG one stage light oil burners series, is a complete range of products developed to respond to any request for heating applications. The Gulliver RG series is available in ten different models, with an output ranging from 16,6 to 309,5 kW, divided in five different structures.
All the models use the same components designed by Riello for the Gulliver series. The high-quality level guarantees safe working.
In developing these burners, special attention was paid to reducing noise, to the easiness of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market..
Two Stage
RL 34
RL 100
RL 130
The RL series of burners covers a fi ring range from 154 to 2700 kW, and it has been designed for use in low or medium temperature hot water boilers, hot air or steam boilers, diathermic oil boilers.
All models are suitable for combustion of light oil and blend of light oil and biodiesel up to 5%. Operation is “two-stage”; the burners are fitted with a microprocessor-based control panel, which supplies indication of burner status and fault causes. Optimization of sound emissions is guaranteed by the special design of the air suction circuit. The elevated performance of the fans and combustion head, guarantee flexibility of use and excellent working at all fi ring rates.
The exclusive design ensures reduced dimensions, simple use and maintenance. A wide range of accessories guarantees elevated working flexibility.
PRESS G Series
The PRESS G series of burners covers a firing range from 107 to 1660 kW and they have been designed for use in civil installations of average dimensions, like building areas and large apartment groups or for use in industrial applications, like small or medium plants.
Operation is two stage; the burners are fitted with a microprocessor-based burner safety control box which supplies indication of operation and diagnosis of fault cause. The combustion head, that can be set on the basis of required output, allows optimal performance ensuring good combustion and reducing fuel consumption. The main feature of these burners is their reliability due to a simple and strong construction, that permits operation without particular maintenance intervention.
Simplified maintenance is achieved by the slide bar system, which allows easy access to all of the essential components of the combustion head. All electrical components are easily accessible only by dismounting a protection panel, thus guaranteeing a quick and simple intervention on components.
Three Stage
PRESS P 450 T/G
The PRESS T/G series of burners covers a firing range from 830 to 5340 kW.
Available in 4 different models, these burners are particularly well suited for matching with pressurized chamber boilers.
For their characteristics, they find application in big civil plants for domestic heating or in industrial applications where thermal load is repetitive and predictable.
A hydraulic ram exclusive system, with 3 adjustable positions, regulates dampers opening, allowing air passage in relation to output required: in this way flame stability is optimized in every working point, with micro-regulation available.
The burners are fitted with a microprocessor-based burner safety control box which supplies indication of operation and diagnosis of fault cause.
Modulating
RL 190/M
The RL/M series of burners covers a fi ring range from 166 to 2431 kW, and they have been designed for use in hot or superheater water boilers, hot air or steam generators, diathermic oil boilers.
Operation can be “two-stage progressive” or, alternatively, “modulating” with the installation of a PID logic regulator and respective probes. RL/M series burners guarantees high efficiency levels in all the various applications, thus reducing fuel consumption and running costs. Optimization of sound emissions is guaranteed by the use of fans with forward inclined blades and sound deadening material incorporated in the air suction circuit.
The exclusive design ensures reduced dimensions, simple use and maintenance. A wide range of accessories guarantees elevated working flexibility.
Press P140 P/G
The PRESS P/G series of burners covers a firing range from 415 to 5340 kW.
Setting can be “two stage progressive” or, alternatively, “modulating” with the installation of a PID logic regulator and respective probes, which guarantees a turn down ratio of 3:1.
The versatility of this range makes the burner well suited for use on commercial or industrial applications where the load factor is subject to wide variations over a short period of time.
Simplified maintenance is achieved by Riello designed slide bar system, which allows easy access to all of the essential components of the combustion head.
Heavy Oil burners
One Stage
40 N20
The Riello 40 N series of one stage heavy oil burners, is a complete range of products developed to respond to any request for the use of heavy oil in heating systems and light
industrial processes. The Riello 40 N series is available in two different models, with an output ranging from 34 to 217 kW, divided into two basic structures.
All the models use many components designed by Riello for the Riello 40 series but are fitted with special components for heavy oil combustion. The high-quality level guarantees safe working. In developing these burners, special attention has been paid to reducing noise, to the ease of installation and adjustment, to reducing the size in order to facilitate installation in any kind of boiler on the market.
All the models are conformed to EMC European Directives, for Low Voltage and Machinery.
Two Stage
PRESS 100N
The PRESS N series of burners covers a firing range from 85 to 1140 kW and they have been designed for use in civil installations of average dimensions, like building areas and large apartment groups or for use in industrial applications, like small or medium plants. Operation is two-stage; a servomotor adjusts automatically air damper opening, to obtain the right air delivery on both stages.
The combustion head, that can be set on the basis of required output, allows optimal performance ensuring good combustion and reducing fuel consumption and is available in two different length to be selected on the basis of specific application requirements. In basic version the burners are supplied for use with heavy oil 7°E viscosity, but they can be supplied with higher viscosity oil with a specific heaters kit.
Simplified maintenance is achieved by the slide bar system, which allows easy access to all of the essential components of the combustion head.
PRESS 30 N ECO
PRESS N/ECO burner series covers a firing range from 171 to 1140 kW and it has been designed for operation with low sulphur fuels. The burners are equipped with a separate low speed pump.
They have been designed for use in civil installations of average dimensions, like building areas and large apartment groups or for use in industrial applications, like small or medium plants.
Operation is two stage; a servomotor adjust automatically air damper opening, to obtain the right air delivery on both stage. The burners are fitted with a microprocessor control panel which supplies indication of operation and diagnosis of fault cause.
The combustion head, that can be set on the basis of required output, allows optimal performance ensuring good combustion and reducing fuel consumption and is available in two different length to be selected on the basis of specific application requirements.
As standard the burners are supplied with electrical heaters installed on crucial parts of hydraulics circuit, for use with heavy oil viscosity up to 20°E.
Simplified maintenance is achieved by the slide bar system, which allows easy access to all of the essential components of the combustion head.
Three Stage
PRESS 450 T/N ECO
The PRESS T/N series of burners covers a firing range from 320 to 5130 kW. They have been designed in three versions for use in commercial and industrial installations, to burn different oil viscosity from 7 up to 60 °E @ 50°C. Operation is three-stage, thus making these burners suitable for installations that have variable but predictable heating requirements.
A servomotor adjusts automatically air damper to the opening value, determined to obtain always the necessary fuel consumption. Every model of PRESS T/N series is available in two different combustion head length (short or long head) to be selected on the basis of specific application requirements. An electric preheater has been fitted to maintain the oil at the correct atomizing temperature at maximum output and special heaters kits are separately supplied for burning high viscosity oil.
Simplified maintenance is achieved by the Riello designed slide bar system, which allows easy access to all of the essential components of the combustion head.
Modulating
PRESS 450 P/N
The PRESS P/N series of burners cover a firing range from 400 to 5130 kW.
Operation can be “two stage-progressive” or, alternatively, “modulating” with the installation of a PID logic regulator and respective probes, which guarantees a turn down ratio of 3:1.
The versatility of this range makes the burner well suited for use on steam boilers where the load factor is subject to wide variations, on thermal oil boilers and on boilers for particular heating plants, as hospitals or similar.
Simplified maintenance is achieved by the Riello designed slide bar system, which allows easy access to all of the essential components of the combustion head.
Natural & LPG Gas Burners
One Stage
Gulliver BS
The Riello Gulliver BS series of one stage gas burners, is a complete range of Low NOx emission products, developed to respond to any request for home heating, conforming to
the most severe standards regarding the reduction of polluting emissions.
This series of burners is available in four different models with an output ranging from 16 to 246 kW, divided in four different structures.
All the models use the same components designed by Riello for the Gulliver series. The high-quality level guarantees safe working. The Gulliver BS burners are fitted with a microprocessor – based flame control panel, with diagnostic functions. In developing these burners, special attention was paid to reducing noise, the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
GS 40
The Riello 40 GS series of one stage gas burners, is a complete range of products developed to respond to any request for home heating. The Riello 40 GS series is available in four different models, with an output ranging from 11 to 220 kW, divided in four different structures.
All the models use the same components designed by Riello for the Riello 40 GS series. The high-quality level guarantees safe working. The Riello 40 GS burners are fitted with a microprocessor-based control box with diagnostic functions.
In developing these burners, special attention was paid to reducing noise, to the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
All the models are approved by the EN 676 European Standard and conform to European Directives for EMC, Low Voltage, Machinery and Boiler Efficiency.
Two Stage
RS 34
The RS burners series covers a fi ring range from 70 to 90 kW, and it has been designed for use in low or medium temperature hot water boilers, hot air or steam boilers, diathermic oil boilers.
Operation is “two-stage progressive”; the burners are fitted with a microprocessor control panel which supplies indication of operation and diagnosis of fault cause.
The elevated performance of the fans and combustion head, guarantee flexibility of use and excellent working at all fi ring rates.
The exclusive design ensures reduced dimensions, simple use and maintenance. A wide range of accessories guarantees elevated working flexibility.
GULLIVER BSD
The Riello Gulliver BSD series of two stage gas burners, is a complete range of Low NOx emission products, developed to respond to any request for home heating, conforming to the most severe standards regarding the reduction of polluting emissions.
This series of burners is available in four different models with an output ranging from 16 to 250 kW, divided in four different structures.
All the models use the same components designed by Riello for the Gulliver series. The high-quality level guarantees safe working. The burners are fitted with a microprocessor-based burner safety control box which supplies indication of operation and diagnosis of fault cause.
In developing these burners, special attention was paid to reducing noise, the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
Two stage working guarantees high level performance from the thermal unit.
All the models are approved by the EN 676 European Standard and conform to European Directives, Gas Appliance, EMC, Low Voltage, Boiler Efficiency.
RIELLO 40 GS D
The Riello 40 GSD series of two stage gas burners, is a complete range of products developed to respond to any request for home heating. The Riello 40 GSD series is available in two different models, with an output ranging from 41 to 220 kW, divided in two different structures.
All the models use the same components designed by Riello for the Riello 40 GSD series. The high-quality level guarantees safe working.
In developing these burners, special attention was paid to reducing noise, to the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
All the models are approved by the EN 676 European Standard and conform to European Directives for EMC, Low Voltage, Gas Appliance and Boiler Efficiency.
Modulating
GAS 9 PM SERIES
The GAS P/M series cover a firing range from 80 to 4885 kW.
Operation is featured by progressive two stage operation or full modulation, with an advanced modulating control system and probes.
The burners of GAS P/M series are well suited for applications requiring versatility of control (process, steam, refrigerating absorption) where a variable output is needed.
Due to their metal sheet structures, they are specifically suitable for process applications where plastic materials could be easily damaged or deformed.
Simplified maintenance is achieved by sliding bars which permit the access to the combustion head without need of removing the burner from the boiler.
RS 44/M
The RS/M burners series covers a firing range from 70 to 2650 kW, and it has been designed for use in low or medium temperature hot water boilers, hot air or steam boilers, diathermic oil boilers.
Operation can be “two-stage progressive” or, alternatively, “modulating” with the installation of a PID logic regulator and respective probes.
RS/M burners series guarantees high efficiency levels in all the various applications, thus reducing fuel consumption and running costs.
The exclusive design ensures reduced dimensions, simple use and maintenance. A wide range of accessories guarantees elevated working flexibility.
Dual Fuel Burners
Two Stage
RLS 28
The RLS series of burners covers a firing range from 100 to 1395 kW, and they have been designed for use in hot or superheater water boilers, hot air or steam generators, diathermic oil boilers.
Operation is “two stage”; the burners are fitted with an electronic device STATUS PANEL, which supplies complete diagnostic: hour meter, ignition meter, identification of trouble shooting.
Optimization of sound emissions is guaranteed by the use of fans with forward inclined blades and sound deadening material incorporated in the air suction circuit.
The elevated performance of the fans and combustion head guarantee flexibility of use and excellent working at all firing rates.
The exclusive design ensures reduced dimensions, simple use and maintenance. A wide range of accessories guarantees elevated working flexibility.
Modulating
GI/EMME 4500
The GI/EMME 1400-4500 series of burners covers a firing range of 407 to 4650 kW. They have been designed for high output users and they are suitable for matching with every kind of boilers, with normal or pressurized combustion chamber.
Operation can be “two-stage progressive” or, alternatively, “modulating” with the installation of a PID logic regulator and respective probes. Two options of operation are available: only gas and only light oil, thus settable by a manual switch.
Light oil circuit is fitted with his own electric motor:
this permits pump-stop during gas operation preventing danger of pumping seizure and avoiding oil circulation. A wide range of accessories and gas trains suitable to the burners guarantee an elevated working flexibility.
ENNE/EMME 4500
The ENNE/EMME 1400-4500 series of burners covers a firing range from 407 to 5000 kW.
They have been designed for high output users and they are suitable for matching with every kind of boilers, with normal or pressurized combustion chamber.
Operation can be “two-stage progressive” or, alternatively, “modulating” with the installation of a PID logic regulator and respective probes. Two fuel options are available: only gas and only heavy oil, thus settable by a manual switch.
Heavy oil circuit is fitted with his own electric motor: this permits pump stop during gas operation preventing danger of pumping seizure and avoiding oil circulation. A wide range of accessories and gas trains suitable to the burners guarantee an elevated working flexibility.
Combustion Technology is the Exclusive Supplier and Distributor of RIELLO in South Africa & Mauritius.
Low NOx Burners
PREMIX
RX S/PV – S/E SERIES
Riello continues to innovate into the future with smart sustainable solutions for ovens and equipment for the artisan and industrial production of bread, all kinds of leavened products and pastry-making.
Riello Burners RX gas burner series, completely designed and developed by Riello Burners for premix combustion technology, is the best answer to low polluting emissions and it allows to achieve high modulating turn down ratios. The RX series burner operation can be “two stages progressive” or alternatively “modulating” with the installation of a PID logic regulator and respective probes. The RX series burners electronic controls are designed with modular concept in order to offer a highly flexible configuration dependant on the application.
Oil
RL 42 BLU
The Riello Gulliver BS series of one stage gas burners, is a complete range of Low NOx emission products, developed to respond to any request for home heating, conforming to
the most severe standards regarding the reduction of polluting emissions.
This series of burners is available in four different models with an output ranging from 16 to 246 kW, divided in four different structures.
All the models use the same components designed by Riello for the Gulliver series. The high-quality level guarantees safe working. The Gulliver BS burners are fitted with a microprocessor – based flame control panel, with diagnostic functions. In developing these burners, special attention was paid to reducing noise, the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
Gas
GULLIVER BS3-M
The Riello Gulliver BS/M series of two stage, progressive or modulating gas burners, is a complete range of Low NOx emission products, developed to respond to any request for heating, conforming to the most severe standards regarding the reduction of polluting emissions.
This series of burners is available in three different models with an output ranging from 49 to 250 kW, divided in three different structures.
All the models use the same components designed by Riello for the Gulliver series. The high-quality level guarantees safe working. In developing these burners, special attention was paid to reducing noise, the ease of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.
Two stage operation guarantees high level performance from the thermal unit. All the models are approved by the EN 676 European Standard, conform to European Directives, Gas Appliance, EMC, Low Voltage, Boiler Efficiency.
Dual
RLS 300/BP
RLS/BP MX series burners are characterized by a modular monoblock structure that means all necessary components can be combined in a single unit thus making installation easier, faster and, above all, more flexible.
The series covers a firing range from 1250 to 4500 kW, and they have been designed for use in hot water boilers, overheated water boilers as well as steam boilers. Burners working is 2 stages on the oil side and two stages progressive on the gas side. Alternatively, the gas working can be modulating with the installation of a PID logic regulator. Using a particular proportioning gas valve, the burner keeps the desired air/gas ratio in every working condition.
The innovative combustion head which is able to reach good performances in term of Low NOx either during gas working or light oil working and reducing noise.
